EATON
EATON 9SX 9SX5KI UPS AC 200/208/220/230/240V 4500Watt 5000VA RS-232 USB PFC
Varenr. · EAN
Pris ved login
priser efter jeres aftale
På lager
Levering 1–2 hverdage · bestil inden 15:00
Beskrivelse
Eaton 9SX5KI, Double-conversion (Online), 5 kVA, 4500 W, Sine, 176 V, 276 V
Specifikationer
| UPS topology | Double-conversion (Online) |
| Output power capacity | 5 kVA |
| Output power | 4500 W |
| Waveform | Sine |
| Input operation voltage (min) | 176 V |
| Input operation voltage (max) | 276 V |
| Input frequency | 40 - 70 Hz |
| Output operation voltage (min) | 200 V |
| Output operation voltage (max) | 240 V |
| Output frequency | 50/60 Hz |
| Number of input phases | 1 |
| Number of output phases | 1 |
| Efficiency | 94.2% |
| Input power factor | 99 |
| Output power factor | 0.9 |
| Output voltage Total Harmonic Distortion (THD) | 3% |
| Noise level | 46 dB |
| Auto power off | Yes |
| AC outlet types | Hardwire |
| USB port | Yes |
| Serial interface | Yes |
| Serial interface type | RS-232 |
| Remote Power Off (RPO)/Remote On-Off (ROO) connector | Yes |
| Battery technology | Sealed Lead Acid (VRLA) |
| Battery capacity | 7 Ah |
| Battery voltage | 12 V |
| Hot-swap battery | Yes |
| Form factor | Tower |
| Product colour | Black |
| Display type | LCD |
| Operating temperature (T-T) | 0 - 40 °C |
| Operating relative humidity (H-H) | 0 - 96% |
| Operating altitude | 0 - 3000 m |
| Compliance certificates | CE |
| Certification | IEC/EN 62040-1, IEC/EN 62040-2, CE, EAC |
| Cables included | Serial, USB cable |
| Quick installation guide | Yes |
| Width | 244 mm |
| Depth | 542 mm |
| Height | 575 mm |
| Weight | 65.5 kg |
| Quantity per pack | 1 pc(s) |
| Nominal output voltage | 230 V |
| Nominal input voltage | 230 V |
